Oil Seal 15x24x5 - F11 - FKM - Viton® - Brown - OSS51564

Oil Seal 15x24x5 - F11 - FKM - Viton® - Brown - OSS51564
Rotation
Inside Diameter 15
Outer Diameter 24
Height 5
Material FPM - VITON
Housing Material Steel
Material Spring SS-304
Spring Yes
Dust lip Yes
Color Brown
Item no. 51564
Stock 0 sentiment_satisfied_alt
keyboard_arrow_down All specifications
Request a quote

All items marked with a * are required.

Specifications
Article number 51564
Color 2Brown
Minimum Order Qty10
ModelOS-F11
TypeOil Seal
Brand Types
DichtomatikVIAS
EriksGRST
SealsupplyOS-F11
Design
MaterialFPM - VITON
Housing MaterialSteel
Material SpringSS-304
SpringYes
Dust lipYes
ColorBrown
TypeOS-F11
Design information (Housing bore)
Housing RoughnessRa = 1.6 - 6.3 μm Rz = 10 - 20 μm Rmax ≤ 25 μm
Housing ToleranceISO H8
Design information (Shaft)
Shaft Hardnessmin. 45 HRC
Shaft RoughnessRa = 0.2 - 0.8 μm Rz = 1 - 5 μm Rmax ≤ 6.3 μm
Shaft ToleranceISO h11
Dimensions
Inside Diameter15
Outer Diameter24
Height5
DIN 376015x24x5
Dimensions15 x 24 x 5
download Download/print specifications PDF
Description
This Oil Seal has the following Dimensions: 15x24x5mm, and the color is Brown. The Material of this item is FPM - VITON The Material of the house is Steel. The model is Oil Seal OS-F11. The Article number of this Oil Seal 15 x 24 x 5 is 51564. And this item has a minimum order Quantity of 10 Pieces

This O-Ring is 24mm and in the color Steel. The Hardness of this Oil Seal 15x24x5 - F11 - FKM - Viton® - Brown - OSS51564 is 15.The alternative names of the compound are and they are mostly produced by Yes. The O-ring is commonly used in and has an operating temperature range from OS-F11 to . O-rings 6592217 are indicated as 51564 and have a DIN 3771 Size of 24. This item is equal to 15x24x5 and has an SS-304 Approval. The chemical name of this Oring is Yes.
