| Stock | Delivery time |
|---|---|
| 224 | Shipped in 35 - 42 - Day(s) |
Shipped in 35 - 42 - Day(s)
| Quantity | Per piece |
|---|---|
| 5+ | € 2,41 |
| 100+ | € 2,10 |
| 250+ | € 1,92 |
| 500+ | € 1,73 |
| In stock | Yes, 224 pcs |
| Article number | 74709 |
| Color 2 | Black |
| Minimum Order Qty | 10 |
| Model | OS-G13 |
| Type | Oil Seal |
| Brand Types | |
| Sealsupply | OS-G13 |
| Design | |
| Material | NBR - Nitrile |
| Housing Material | Steel |
| Spring | No |
| Dust lip | Yes |
| Color | Black |
| Type | OS-G13 |
| Design information (Housing bore) | |
| Housing Roughness | Ra = 1.6 - 6.3 μm Rz = 10 - 20 μm Rmax ≤ 25 μm |
| Housing Tolerance | ISO H8 |
| Design information (Shaft) | |
| Shaft Hardness | min. 45 HRC |
| Shaft Roughness | Ra = 0.2 - 0.8 μm Rz = 1 - 5 μm Rmax ≤ 6.3 μm |
| Shaft Tolerance | ISO h11 |
| Dimensions | |
| Inside Diameter | 17 |
| Outer Diameter | 25 |
| Height | 3 |
| DIN 3760 | 17x25x3 |
| Dimensions | 17 x 25 x 3 |
This O-Ring is 25mm and in the color Steel. The Hardness of this Oil Seal 17x25x3 - G13 - NBR - Nitrile - Black - OSS74709 is 17.The alternative names of the compound are and they are mostly produced by Yes. The O-ring is commonly used in and has an operating temperature range from OS-G13 to . O-rings 6527116 are indicated as 74709 and have a DIN 3771 Size of 25. This item is equal to 17x25x3 and has an Approval. The chemical name of this Oring is No.
