| Stock | Delivery time |
|---|---|
| 58 | On workingdays before 12:00 ordered, shipped the same day |
| 2.749 | Shipped in 35 - 42 - Day(s) |
Before 12:00 ordered, shipped the same day
| Quantity | Per piece |
|---|---|
| 5+ | € 2,41 |
| 100+ | € 2,10 |
| 250+ | € 1,92 |
| 500+ | € 1,73 |
| In stock | Yes, 2807 pcs |
| Article number | 79578 |
| Color 2 | Green |
| Minimum Order Qty | 10 |
| Model | VC |
| Type | Oil Seal |
| Brand Types | |
| Dichtomatik | WAOK |
| Ebele | RZV |
| Eriks | RGZV |
| Freudenberg | BAOF |
| KACO | DE |
| Kimman | KAOW |
| NOK | VC |
| Sealsupply | OS-G12 |
| Stefa | CD |
| Taiwan | VC |
| Design | |
| Material | NBR - Nitrile |
| Housing Material | Steel |
| Spring | No |
| Dust lip | No |
| Color | Green |
| Type | VC |
| Design information (Housing bore) | |
| Housing Roughness | Ra = 1.6 - 6.3 μm Rz = 10 - 20 μm Rmax ≤ 25 μm |
| Housing Tolerance | ISO H8 |
| Design information (Shaft) | |
| Shaft Hardness | min. 45 HRC |
| Shaft Roughness | Ra = 0.2 - 0.8 μm Rz = 1 - 5 μm Rmax ≤ 6.3 μm |
| Shaft Tolerance | ISO h11 |
| Dimensions | |
| Inside Diameter | 20 |
| Outer Diameter | 27 |
| Height | 4 |
| DIN 3760 | 20x27x4 |
| Dimensions | 20 x 27 x 4 |
This O-Ring is 27mm and in the color Steel. The Hardness of this Oil Seal 20x27x4 - VC - NBR - Nitrile - Green - OSS79578 is 20.The alternative names of the compound are and they are mostly produced by No. The O-ring is commonly used in VC and has an operating temperature range from VC to . O-rings 6586659 are indicated as 79578 and have a DIN 3771 Size of 27. This item is equal to 20x27x4 and has an Approval. The chemical name of this Oring is No.
