Oil Seal 22x28x4 - VC - VMQ - Silicone - Red - OSS78842

Oil Seal 22x28x4 - VC - VMQ - Silicone - Red - OSS78842
Rotation
Inside Diameter 22
Outer Diameter 28
Height 4
Material VMQ - SILICONE
Housing Material Steel
Spring No
Dust lip No
Color Red
Item no. 78842
Stock 23 sentiment_satisfied_alt
keyboard_arrow_down All specifications
Request a quote

All items marked with a * are required.

Specifications
In stock Yes, 23 pcs
Article number 78842
Color 2Red
Country of OriginTW
Minimum Order Qty10
ModelVC
TypeOil Seal
Brand Types
DichtomatikWAOK
EbeleRZV
EriksRGZV
FreudenbergBAOF
KACODE
KimmanKAOW
NOKVC
SealsupplyOS-G12
StefaCD
TaiwanVC
Design
MaterialVMQ - SILICONE
Housing MaterialSteel
SpringNo
Dust lipNo
ColorRed
TypeVC
Design information (Housing bore)
Housing RoughnessRa = 1.6 - 6.3 μm Rz = 10 - 20 μm Rmax ≤ 25 μm
Housing ToleranceISO H8
Design information (Shaft)
Shaft Hardnessmin. 45 HRC
Shaft RoughnessRa = 0.2 - 0.8 μm Rz = 1 - 5 μm Rmax ≤ 6.3 μm
Shaft ToleranceISO h11
Dimensions
Inside Diameter22
Outer Diameter28
Height4
DIN 376022x28x4
Dimensions22 x 28 x 4
download Download/print specifications PDF
Description
This Oil Seal has the following Dimensions: 22x28x4mm, and the color is Red. The Material of this item is VMQ – SILICONE The Material of the house is Steel. The model is Oil Seal VC. The Article number of this Oil Seal 22 x 28 x 4 is 78842. And this item has a minimum order Quantity of 10 Pieces

This O-Ring is 28mm and in the color Steel. The Hardness of this Oil Seal 22x28x4 - VC - VMQ - Silicone - Red - OSS78842 is 22.The alternative names of the compound are and they are mostly produced by No. The O-ring is commonly used in VC and has an operating temperature range from VC to . O-rings 6582401 are indicated as 78842 and have a DIN 3771 Size of 28. This item is equal to 22x28x4 and has an Approval. The chemical name of this Oring is No.
