This O-Ring has a diameter of 12 mm and is Steel in color. The hardness of this Oil Seal 6x12x2 - VC - FKM - Viton® - Brown - OSS56351 is 6. Alternative names for the compound are , and it is commonly produced by . The O-Ring is typically used in VC and has an operating temperature range from VC to . O-Rings 6531029 are referred to as 56351 and have a DIN 3771 size of 12. This item is equivalent to 6x12x2 and has an approval. The chemical name of this O-Ring is .
| Article number | 56351 |
| Model | VC |
| Color 2 | Brown |
| Country of Origin | TW |
| Minimum Order Qty | 10 |
| Type | Oil Seal |
| Inside Diameter | 6 |
| Brand Types | |
| Dichtomatik | WAO |
| Elring | ADF |
| Eriks | RZV |
| FP Paris | GSM |
| Freudenberg | BA OF |
| Gaco | SA |
| GOETZE | 827 NO |
| KACO | DE |
| Kimman | KAOW |
| Kramp | CD |
| NOK | VC |
| Paulstra | IO |
| Pioneer W | R26 |
| Rolf | LSM |
| Sealsupply | OS-A12 |
| Stefa | CD |
| Taiwan | VC |
| Vota | AOF |
| Design | |
| Material | FPM - VITON |
| Color | Brown |
| Housing Material | Steel |
| Type | VC |
| Design information (Housing bore) | |
| Housing Roughness | Ra = 1.6 - 6.3 μm Rz = 10 - 20 μm Rmax ≤ 25 μm |
| Housing Tolerance | ISO H8 |
| Design information (Shaft) | |
| Shaft Hardness | min. 45 HRC |
| Shaft Roughness | Ra = 0.2 - 0.8 μm Rz = 1 - 5 μm Rmax ≤ 6.3 μm |
| Shaft Tolerance | ISO h11 |
| Dimensions | |
| Dimensions | 6 x 12 x 2 |
| DIN 3760 | 6x12x2 |
| Outer Diameter | 12 |
| Height | 2 |
