V-rings Type VS

Design, construction and operation

Applications: where the VS (S10) excels

You mainly see the V-ring VS (S10) where space is limited and where vibration, contamination or splash water plays a role. In agricultural machinery this is typical because there is a lot of mud, sand, manure and water present, and the extra shaft grip helps prevent shifting or loosening. The VS V-ring is also often used in industry and drives such as electric motors, gearboxes and conveyor rollers to protect the bearing arrangement and a seal behind it. In addition, you will find this type in vehicle and off-road applications and in heavier machine building, where a robust first line of defense is needed against dirt and water while the available installation space remains limited. In short, the VS is intended for situations where you want a V-ring that is compact but still stays stable in position.

Materials: NBR or FKM

For most VS (S10) V-rings, you will in practice choose between NBR or FKM (Viton®). NBR is the standard choice for general industrial applications thanks to its good resistance to oil and grease and its solid wear resistance. You choose FKM when temperatures are higher or when you need greater chemical resistance; this is usually the “premium” option. Other materials, such as EPDM, HNBR, CR (neoprene) and VMQ (silicone), are available on request for specific environments (e.g. weather/ozone/UV or extreme temperatures).

Material Table

Comparing VS (S10) with VA, VL and VE

The V-ring VA is the standard and most universal design with the widest size range; it is compact and easy to use in many machines. The V-ring VS (S10) is the slimmer variant with typically more grip on the shaft due to the conically extended clamping section, making it more stable under vibration and at higher speeds, and particularly interesting when radial installation space is limited. The V-ring VL (L10/lightweight) is lighter and thinner and often becomes attractive at larger diameters to limit mass and centrifugal effects, but it is generally less robust in very heavy contamination. The V-ring VE is the heavy-duty variant for very large diameters and harsh industrial conditions; it is robust but requires more installation space and sometimes more attention during installation.

How to choose the right VS (S10) V-ring

The choice starts with the shaft size, because sizing is generally linked to the nominal shaft diameter and the ring clamps onto the shaft by preload. Then you look at the available installation space: the VS V-ring is especially interesting when radial space is limited, but you must ensure you can position the ring axially against a suitable counterface. Next, you select the material based on the medium and the environment. For standard grease and oil environments at normal temperatures, NBR is the obvious choice; at higher temperatures or with chemical exposure, FKM is often the next step; for outdoor use and water-based environments, EPDM can be a logical option, provided mineral oil or grease is not dominant. Consider the operating conditions as well: a V-ring VS (S10) is essentially a pressure-free axial seal and is not intended to hold system pressure; it can retain a little grease or oil mist, but under real pressure the lip will tend to deflect or leak. Speed also matters: circumferential speeds up to about 10–12 m/s are often considered safe for continuous contact operation. Up to roughly 10 m/s, friction losses typically increase almost linearly with circumferential speed; around 15–20 m/s the lip pressure can decrease due to centrifugal force and the ring starts to function more like a splash flange or “slinger” (less friction and wear, but different sealing behavior). The counterface remains crucial in all cases: it must be clean, flat and sufficiently rigid to provide even contact. Finally, take the level of contamination into account, because in heavily contaminated environments additional shielding (such as a splash guard or more robust protection) can make a significant difference in service life, especially since temperature, medium and speed together determine how long the ring continues to perform properly.

Cross Reference

In summary, the V-Ring S10 is a specialized rotary seal designed with an additional conically extended retaining part for enhanced secure seating on the shaft. Its purpose is to provide optimal shaft sealing, preventing the ingress of contaminants and leakage of grease. With its design enhancement, the V-Ring S10 ensures reliable and effective sealing performance, even in demanding operating conditions. Choose the V-Ring S10 for superior shaft sealing solutions with enhanced secure seating.

If you would like more information, of if you do not know which Ring you should have, feel free to contact us.
