| Stock | Delivery time |
|---|---|
| 16 | Ordered Before 13:00, shipped the same day |
| 788 | Shipped in 5 - 7 - Day(s) |
Ordered Before 13:00, shipped the same day
| Quantity | Per piece |
|---|---|
| 4+ | € 2,98 |
| 50+ | € 2,55 |
| 100+ | € 2,35 |
| 250+ | € 2,14 |
| 500+ | € 2,04 |
| 1000+ | € 1,84 |
| 2500+ | € 1,60 |
| In stock | Yes, 804 pcs |
| Article number | 71409 |
| Color 2 | Blue |
| Minimum Order Qty | 2 |
| Model | TCN |
| Seal | Oil Seal |
| Brand Types | |
| Dichtomatik | WASY |
| Eriks | RST-D |
| FP Paris | GAP |
| Freudenberg | BABSL |
| GOETZE | 827 SK |
| KACO | DGSP |
| Kimman | KAS-P |
| Kramp | BABSL |
| NOK | TCN |
| Sealsupply | OS-N21 |
| Stefa | CF |
| Taiwan | TCV |
| Design | |
| Material | NBR - Nitrile |
| Spring | Yes |
| Dust lip | Yes |
| Color | Blue |
| Type | TCN High Pressure |
| Design information (Housing bore) | |
| Housing Roughness | Ra = 1.6 - 6.3 μm Rz = 10 - 20 μm Rmax ≤ 25 μm |
| Housing Tolerance | ISO H8 |
| Design information (Shaft) | |
| Shaft Hardness | min. 45 HRC |
| Shaft Roughness | Ra = 0.2 - 0.8 μm Rz = 1 - 5 μm Rmax ≤ 6.3 μm |
| Shaft Tolerance | ISO h11 |
| Dimensions | |
| Inside Diameter | 20 |
| Outer Diameter | 30 |
| Height | 4.5 |
| DIN 3760 | 20x30x4,5 |
| Dimensions | 20 x 30 x 4,5 |
This Oil Seal has the following Dimensions: 20x30x4,5mm, and the color is Blue. The Material of this item is NBR – Nitrile The Material of the house is . The model is Oil Seal TCN. The Article number of this Oil Seal 20 x 30 x 4,5 is 71409. And this item has a minimum order Quantity of 2 Pieces This O-Ring is 30mm and in the color . The Hardness of this Oil Seal 20x30x4,5 TCN NBR - Nitrile Blue OSS71409 is 20.The alternative names of the compound are and they are mostly produced by Yes. The O-ring is commonly used in TCV and has an operating temperature range from TCN High Pressure to . O-rings 126119 are indicated as 71409 and have a DIN 3771 Size of 30. This item is equal to 20x30x4,5 and has an Approval. The chemical name of this Oring is Yes.
