5.500.000+ parts in stock
Fast delivery
| Quantity | Per piece |
|---|---|
| 1+ | € 66,4400 |
| 2+ | € 57,7600 |
| 3+ | € 52,5200 |
| 5+ | € 47,7400 |
| 10+ | € 45,3600 |
| 15+ | € 43,1000 |
| 25+ | € 40,9400 |
| 50+ | € 38,9000 |
This O-Ring has a diameter of 60 mm and is SS-316 in color. The hardness of this Oil Seal 40x60x10 - PA31 - PTFE - Black - OSS73829 is 40. Alternative names for the compound are , and it is commonly produced by . The O-Ring is typically used in and has an operating temperature range from OS-PA31 to . O-Rings 424115 are referred to as 73829 and have a DIN 3771 size of 60. This item is equivalent to 40x60x10 and has an approval. The chemical name of this O-Ring is .
| Article number | 73829 |
| Model | OS-PA31 |
| Color 2 | Black |
| Country of Origin | TW |
| Material options | FKM |
| Minimum Order Qty | 2 |
| Type | Oil Seal |
| Brand Types | |
| Sealsupply | OS-PA31 |
| Design | |
| Material | PTFE |
| Color | Black |
| Housing Material | SS-316 |
| Type | OS-PA31 |
| Design information (Housing bore) | |
| Housing Roughness | Ra = 0.8 - 3,2 μm Rz = 6.3 - 16 μm Rmax ≤ 16 μm |
| Housing Tolerance | ISO H8 |
| Design information (Shaft) | |
| Shaft Hardness | min. 50 HRC |
| Shaft Roughness | Ra = 0.2 - 0.8 μm Rz = 1 - 5 μm Rmax ≤ 6.3 μm |
| Shaft Tolerance | ISO h11 |
| Dimensions | |
| Dimensions | 40 x 60 x 10 |
| DIN 3760 | 40x60x10 |
| Inside Diameter | 40 |
| Outer Diameter | 60 |
| Height | 10 |
All items marked with a * are required.
| Quantity | Per piece |
|---|---|
| 1+ | € 66,4400 |
| 2+ | € 57,7600 |
| 3+ | € 52,5200 |
| 5+ | € 47,7400 |
| 10+ | € 45,3600 |
| 15+ | € 43,1000 |
| 25+ | € 40,9400 |
| 50+ | € 38,9000 |
