| Stock | Delivery time |
|---|---|
| 17 | Shipped in 5 - 7 - Day(s) |
Shipped in 5 - 7 - Day(s)
| Quantity | Per piece |
|---|---|
| 1+ | € 92,70 |
| 2+ | € 80,62 |
| 3+ | € 73,28 |
| 5+ | € 66,62 |
| 10+ | € 63,30 |
| 15+ | € 60,12 |
| 25+ | € 57,12 |
| 50+ | € 54,26 |
| In stock | Yes, 17 pcs |
| Article number | 71860 |
| Color 2 | Black |
| Material options | FKM |
| Minimum Order Qty | 2 |
| Model | OS-PA31 |
| Type | Oil Seal |
| Brand Types | |
| Sealsupply | OS-PA31 |
| Design | |
| Material | PTFE |
| Housing Material | SS-316 |
| Color | Black |
| Type | OS-PA31 |
| Design information (Housing bore) | |
| Housing Roughness | Ra = 0.8 - 3,2 μm Rz = 6.3 - 16 μm Rmax ≤ 16 μm |
| Housing Tolerance | ISO H8 |
| Design information (Shaft) | |
| Shaft Hardness | min. 50 HRC |
| Shaft Roughness | Ra = 0.2 - 0.8 μm Rz = 1 - 5 μm Rmax ≤ 6.3 μm |
| Shaft Tolerance | ISO h11 |
| Dimensions | |
| Inside Diameter | 55 |
| Outer Diameter | 72 |
| Height | 10 |
| DIN 3760 | 55x72x10 |
| Dimensions | 55 x 72 x 10 |
This O-Ring is 72mm and in the color SS-316. The Hardness of this Oil Seal 55x72x10 - PA31 - PTFE - Black - OSS71860 is 55.The alternative names of the compound are and they are mostly produced by . The O-ring is commonly used in and has an operating temperature range from OS-PA31 to . O-rings 288137 are indicated as 71860 and have a DIN 3771 Size of 72. This item is equal to 55x72x10 and has an Approval. The chemical name of this Oring is .
